Mikrotik Metal 2SHPn
The new, completely waterproof, rugged, and super high
powered RouterBOARD Metal. The serious outdoor wireless device. Now
in 2.4Ghz with amazing 1600mW TX power!
Fully sealed, industrial design metal case, powered by RouterBOARD
and RouterOS. 1.6 WATT of output power - to reach the last mile, in
any conditions. It comes with L4 license, so you can attach your favorite
antennna to use it as an AP, to make wireless point-to-point links or
as a CPE- whatever you prefer!
It has a built-in N-male connector, and pole attachment points, so
you can attach it to an antenna directly, or use a standard antenna
cable. LED signal indicators make it easy to install and align.
Package contains Metal-2SHPn, mounting loops, PoE injector, power adapter
| Details |
|---|
| Product code | RBMetal2SHPn | | CPU speed | 400MHz | | RAM | 64MB | | Architecture | MIPS-BE | | LAN ports | 1 | | Gigabit | No | | MiniPCI | 0 | | Integrated Wireless | Yes | | Wireless standards | 802.11b/g/n | | Power Jack | No | | 802.3af support | No | | PoE | 8-30V DC | | Voltage Monitor | yes | | PCB temperature monitor | yes | | CPU temperature monitor | No | | Dimensions | 177x44x44mm, 193g | | Operating System | RouterOS | | Temperature range | -30C to +70C | | RouterOS License | Level4 | | Current Monitor | no | | TX power | 32dBm | | CPU | AR7241 | | Max Power consumption | 11.5W |
Performance test results| RBMetal2SHPn | One Fast Ethernet port test (400Mhz) | RouterOS v6.0rc6 | | | Mode | Configuration | 64 byte | 512 byte | 1518 byte | | kpps | Mbps | kpps | Mbps | kpps | Mbps | | Bridging | fast path | 148.0 | 97.1 | 23.5 | 99.6 | 8.1 | 99.8 | | Bridging | 25 Bridge filter rules | 53.7 | 35.2 | 23.5 | 99.6 | 8.1 | 99.8 | | Routing | fast path | 148.0 | 97.1 | 23.5 | 99.6 | 8.1 | 99.8 | | Routing | 25 Simple Queues | 92.8 | 60.8 | 23.5 | 99.6 | 8.1 | 99.8 | | Routing | 25 Firewall filter rules | 37.5 | 24.6 | 23.5 | 99.6 | 8.1 | 99.8 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
|
